Playground

Type Carve on the left, see the rendered HTML on the right (and the raw HTML below). Everything runs client-side, no network round-trip — the same reference parser that backs the spec corpus.

Carve source

---
title: Carve Feature Demo
date: 2026-06-02
author: Carve
tags: [demo, reference]
---

%% This file exercises the Carve markup constructs supported by the grammar.
%% Lines beginning with %% are comments and do not render.

{#top}
# Carve Feature Demo

A single document touching every core construct, plus a few renderer-dependent
extensions at the end. Open it with **Carve: Open Preview** to see it rendered.

{#headings .featured}
## Headings and attributes

# Level 1
## Level 2
### Level 3
#### Level 4
##### Level 5
###### Level 6

A heading carries an explicit id and classes from a block-attribute line on
the line directly above it:

```carve
{#install .lead}
## Setup
```

## Inline formatting

/italic/, *bold*, /*bold italic*/, _underline_, ~strikethrough~, =highlight=,
super{^script^} and sub{,script,}. Inline `code span`, and raw inline passthrough
`<abbr>HTML</abbr>`{=html} emitted verbatim.

Editorial markup: {+ added text +}, {- deleted text -},
{~ old phrase ~> new phrase ~}, and an {# editorial note #}.

Escapes keep specials literal: \*not bold\*, \/not italic\/, \#not-a-tag.

## Links and images

Inline [link](https://example.com), titled
[link](https://example.com "Hover title"), autolink <https://example.com>,
email autolink <hello@example.com>, and a reference [link][site].

A collapsed reference [site][] reuses the label as the reference.

Cross-reference to a heading by id: jump to </#top>.

[site]: https://example.com "Reference definition"

![A descriptive alt text](images/diagram.png)
^ Figure 1: images may carry a caption line.

## Lists

Unordered:

- apples
- oranges
  - clementines
  - blood oranges
- pears

Ordered:

1. clone the repo
2. install dependencies
   - run the build
   - run the tests
3. ship it

Tasks:

- [x] write the grammar
- [x] write the corpus
- [ ] write more demos

Definition list:

:: Carve
:  A post-Markdown lightweight markup language.
:: Djot
:  The markup language Carve evolves from.

## Blockquotes

> The best way to predict the future is to invent it.
^ Alan Kay

## Tables

|= Fruit       |=> Price |=~ Stock |
| Apple        |    1.20 |   In     |
| Banana       |    0.50 |   In     |
| Dragon fruit |    4.00 |   Out    |
^ Table 1: column alignment - left, right, center.

## Code and raw blocks

A fenced code block with a language:

```python
def greet(name: str) -> str:
    return f"Hello, {name}!"
```

A tilde fence works too:

~~~yaml
key: value
list:
  - one
  - two
~~~

A raw block passes content through to a named format unchanged:

```=html
<details><summary>Native HTML</summary>Rendered as-is.</details>
```

## Math

Inline math uses a dollar before a code span: $`e = mc^2`.

Display math uses a double dollar:

$$`\int_0^\infty e^{-x^2}\,dx = \frac{\sqrt{\pi}}{2}`

## Admonitions and divs

::: note
A plain note callout.
:::

::: tip "With a title"
Admonitions accept an optional quoted title.
:::

::: warning
Heed this warning.
:::

::: danger
Critical information.
:::

A bare `:::` fence with no admonition type is a generic styled container, not a
colored callout. Its id and classes go on a block-attribute line directly above
the fence:

{#callout .highlight}
:::
This block has only an id and classes, so it renders as a plain
`<div id="callout" class="highlight">` wrapper you can target with your own CSS.
:::

## Mentions, tags, and inline extensions

Mention a person with @alice and reference a tag like #release-1.0.
An inline extension names a role: press :kbd[Ctrl+C] to copy.

## Footnotes

Carve supports footnotes[^note] with definitions collected anywhere.[^second]

[^note]: The reference and its definition are linked by label.
[^second]: Definitions can appear in any order.

## Smart typography

Dashes and ellipsis: an em dash --- an en range 10--20 ... and so on.
Arrows and comparisons: -> <- <-> => , != <= >= , (c) (r) (tm).

---

## Mermaid (Tier-3 extension)

%% Mermaid is a third-party extension, not core Carve. It is written as a
%% fenced code block tagged `mermaid`. It only renders as a diagram when the
%% renderer enables the Mermaid extension; otherwise it shows as a code block.

```mermaid
graph TD
    A[Write Carve] --> B{LSP diagnostics}
    B -->|clean| C[Preview]
    B -->|warnings| D[Quick fix]
    D --> A
    C --> E[Publish]
```

```mermaid
sequenceDiagram
    Author->>Editor: type Carve
    Editor->>LSP: textDocument/didChange
    LSP-->>Editor: diagnostics + semantic tokens
    Editor-->>Author: live preview
```

Rendered HTML

Carve Feature Demo

A single document touching every core construct, plus a few renderer-dependent extensions at the end. Open it with **Carve: Open Preview** to see it rendered.

Headings and attributes

Level 1

Level 2

Level 3

Level 4

Level 5

Level 6

A heading carries an explicit id and classes from a block-attribute line on the line directly above it:

{#install .lead}
## Setup

Inline formatting

italic, bold, bold italic, underline, ~~strikethrough~~, highlight, super^script and sub_script. Inline code span, and raw inline passthrough HTML emitted verbatim.

Editorial markup: added text , ~~deleted text~~ , ~~old phrase~~ new phrase , and an editorial note .

Escapes keep specials literal: *not bold*, /not italic/, #not-a-tag.

Links and images

Inline link, titled link, autolink https://example.com, email autolink hello@example.com, and a reference link.

A collapsed reference site reuses the label as the reference.

Cross-reference to a heading by id: jump to Carve Feature Demo.

A descriptive alt text — Figure 1: images may carry a caption line.

Lists

Unordered:

apples
oranges
- clementines
- blood oranges
pears

Ordered:

clone the repo
install dependencies
- run the build
- run the tests
ship it

Tasks:

write the grammar
write the corpus
write more demos

Definition list:

Carve: A post-Markdown lightweight markup language.
Djot: The markup language Carve evolves from.

Blockquotes

The best way to predict the future is to invent it.

Alan Kay

Tables

Table 1: column alignment - left, right, center.
Fruit	Price	Stock
Apple	1.20	In
Banana	0.50	In
Dragon fruit	4.00	Out

Code and raw blocks

A fenced code block with a language:

def greet(name: str) -> str:
    return f"Hello, {name}!"

A tilde fence works too:

key: value
list:
  - one
  - two

A raw block passes content through to a named format unchanged:

Native HTML

Rendered as-is.

Math

Inline math uses a dollar before a code span: $e = mc^2$.

Display math uses a double dollar:

\[\int_0^\infty e^{-x^2}\,dx = \frac{\sqrt{\pi}}{2}\]

Admonitions and divs

A bare ::: fence with no admonition type is a generic styled container, not a colored callout. Its id and classes go on a block-attribute line directly above the fence:

This block has only an id and classes, so it renders as a plain <div id="callout" class="highlight"> wrapper you can target with your own CSS.

Mentions, tags, and inline extensions

Mention a person with @alice and reference a tag like #release-1.0. An inline extension names a role: press Ctrl+C to copy.

Footnotes

Carve supports footnotes¹ with definitions collected anywhere.²

Smart typography

Mermaid (Tier-3 extension)

graph TD
    A[Write Carve] --> B{LSP diagnostics}
    B -->|clean| C[Preview]
    B -->|warnings| D[Quick fix]
    D --> A
    C --> E[Publish]

sequenceDiagram
    Author->>Editor: type Carve
    Editor->>LSP: textDocument/didChange
    LSP-->>Editor: diagnostics + semantic tokens
    Editor-->>Author: live preview

The reference and its definition are linked by label.↩
Definitions can appear in any order.↩

HTML source

<section id="top">
  <h1>Carve Feature Demo</h1>
  <p>A single document touching every core construct, plus a few renderer-dependent
extensions at the end. Open it with **Carve: Open Preview** to see it rendered.</p>
  <section id="headings">
    <h2 class="featured">Headings and attributes</h2>
  </section>
</section>
<section id="level-1">
  <h1>Level 1</h1>
  <section id="level-2">
    <h2>Level 2</h2>
    <section id="level-3">
      <h3>Level 3</h3>
      <section id="level-4">
        <h4>Level 4</h4>
        <section id="level-5">
          <h5>Level 5</h5>
          <section id="level-6">
            <h6>Level 6</h6>
            <p>A heading carries an explicit id and classes from a block-attribute line on
the line directly above it:</p>
            <pre><code class="language-carve">{#install .lead}
## Setup
</code></pre>
          </section>
        </section>
      </section>
    </section>
  </section>
  <section id="inline-formatting">
    <h2>Inline formatting</h2>
    <p><em>italic</em>, <strong>bold</strong>, <strong><em>bold italic</em></strong>, <u>underline</u>, <s>strikethrough</s>, <mark>highlight</mark>,
super<sup>script</sup> and sub<sub>script</sub>. Inline <code>code span</code>, and raw inline passthrough
<abbr>HTML</abbr> emitted verbatim.</p>
    <p>Editorial markup: <ins> added text </ins>, <del> deleted text </del>,
<del> old phrase </del><ins> new phrase </ins>, and an <span class="critic-comment"> editorial note </span>.</p>
    <p>Escapes keep specials literal: *not bold*, /not italic/, #not-a-tag.</p>
  </section>
  <section id="links-and-images">
    <h2>Links and images</h2>
    <p>Inline <a href="https://example.com">link</a>, titled
<a href="https://example.com" title="Hover title">link</a>, autolink <a href="https://example.com">https://example.com</a>,
email autolink <a href="mailto:hello@example.com">hello@example.com</a>, and a reference <a href="https://example.com" title="Reference definition">link</a>.</p>
    <p>A collapsed reference <a href="https://example.com" title="Reference definition">site</a> reuses the label as the reference.</p>
    <p>Cross-reference to a heading by id: jump to <a href="#top">Carve Feature Demo</a>.</p>
    <figure>
      <img src="/carve/images/diagram.png" alt="A descriptive alt text">
      <figcaption>Figure 1: images may carry a caption line.</figcaption>
    </figure>
  </section>
  <section id="lists">
    <h2>Lists</h2>
    <p>Unordered:</p>
    <ul>
      <li>apples</li>
      <li>oranges
        <ul>
          <li>clementines</li>
          <li>blood oranges</li>
        </ul>
      </li>
      <li>pears</li>
    </ul>
    <p>Ordered:</p>
    <ol>
      <li>clone the repo</li>
      <li>install dependencies
        <ul>
          <li>run the build</li>
          <li>run the tests</li>
        </ul>
      </li>
      <li>ship it</li>
    </ol>
    <p>Tasks:</p>
    <ul>
      <li><input type="checkbox" checked disabled> write the grammar</li>
      <li><input type="checkbox" checked disabled> write the corpus</li>
      <li><input type="checkbox" disabled> write more demos</li>
    </ul>
    <p>Definition list:</p>
    <dl>
      <dt>Carve</dt>
      <dd>A post-Markdown lightweight markup language.</dd>
      <dt>Djot</dt>
      <dd>The markup language Carve evolves from.</dd>
    </dl>
  </section>
  <section id="blockquotes">
    <h2>Blockquotes</h2>
    <figure>
      <blockquote><p>The best way to predict the future is to invent it.</p></blockquote>
      <figcaption>Alan Kay</figcaption>
    </figure>
  </section>
  <section id="tables">
    <h2>Tables</h2>
    <table>
      <caption>Table 1: column alignment - left, right, center.</caption>
      <thead><tr><th>Fruit</th><th style="text-align: right;">Price</th><th style="text-align: center;">Stock</th></tr></thead>
      <tbody>
        <tr><td>Apple</td><td style="text-align: right;">1.20</td><td style="text-align: center;">In</td></tr>
        <tr><td>Banana</td><td style="text-align: right;">0.50</td><td style="text-align: center;">In</td></tr>
        <tr><td>Dragon fruit</td><td style="text-align: right;">4.00</td><td style="text-align: center;">Out</td></tr>
      </tbody>
    </table>
  </section>
  <section id="code-and-raw-blocks">
    <h2>Code and raw blocks</h2>
    <p>A fenced code block with a language:</p>
    <pre><code class="language-python">def greet(name: str) -&gt; str:
    return f"Hello, {name}!"
</code></pre>
    <p>A tilde fence works too:</p>
    <pre><code class="language-yaml">key: value
list:
  - one
  - two
</code></pre>
    <p>A raw block passes content through to a named format unchanged:</p>
<details><summary>Native HTML</summary>Rendered as-is.</details>
  </section>
  <section id="math">
    <h2>Math</h2>
    <p>Inline math uses a dollar before a code span: <span class="math inline">\(e = mc^2\)</span>.</p>
    <p>Display math uses a double dollar:</p>
    <p><span class="math display">\[\int_0^\infty e^{-x^2}\,dx = \frac{\sqrt{\pi}}{2}\]</span></p>
  </section>
  <section id="admonitions-and-divs">
    <h2>Admonitions and divs</h2>
    <aside class="admonition note">
      <p>A plain note callout.</p>
    </aside>
    <aside class="admonition tip">
      <p class="admonition-title">With a title</p>
      <p>Admonitions accept an optional quoted title.</p>
    </aside>
    <aside class="admonition warning">
      <p>Heed this warning.</p>
    </aside>
    <aside class="admonition danger">
      <p>Critical information.</p>
    </aside>
    <p>A bare <code>:::</code> fence with no admonition type is a generic styled container, not a
colored callout. Its id and classes go on a block-attribute line directly above
the fence:</p>
    <div id="callout" class="highlight">
      <p>This block has only an id and classes, so it renders as a plain
<code>&lt;div id="callout" class="highlight"&gt;</code> wrapper you can target with your own CSS.</p>
    </div>
  </section>
  <section id="mentions-tags-and-inline-extensions">
    <h2>Mentions, tags, and inline extensions</h2>
    <p>Mention a person with <span class="mention"><strong>@alice</strong></span> and reference a tag like <span class="tag"><strong>#release-1.0</strong></span>.
An inline extension names a role: press <kbd>Ctrl+C</kbd> to copy.</p>
  </section>
  <section id="footnotes">
    <h2>Footnotes</h2>
    <p>Carve supports footnotes<a id="fnref1" href="#fn1" role="doc-noteref"><sup>1</sup></a> with definitions collected anywhere.<a id="fnref2" href="#fn2" role="doc-noteref"><sup>2</sup></a></p>
  </section>
  <section id="smart-typography">
    <h2>Smart typography</h2>
    <p>Dashes and ellipsis: an em dash — an en range 10–20 … and so on.
Arrows and comparisons: → ← ↔ ⇒ , ≠ ≤ ≥ , © ® ™.</p>
    <hr>
  </section>
  <section id="mermaid-tier-3-extension">
    <h2>Mermaid (Tier-3 extension)</h2>
    <pre><code class="language-mermaid">graph TD
    A[Write Carve] --&gt; B{LSP diagnostics}
    B --&gt;|clean| C[Preview]
    B --&gt;|warnings| D[Quick fix]
    D --&gt; A
    C --&gt; E[Publish]
</code></pre>
    <pre><code class="language-mermaid">sequenceDiagram
    Author-&gt;&gt;Editor: type Carve
    Editor-&gt;&gt;LSP: textDocument/didChange
    LSP--&gt;&gt;Editor: diagnostics + semantic tokens
    Editor--&gt;&gt;Author: live preview
</code></pre>
  </section>
</section>
<section role="doc-endnotes">
  <hr>
  <ol>
    <li id="fn1">
      <p>The reference and its definition are linked by label.<a href="#fnref1" role="doc-backlink">↩</a></p>
    </li>
    <li id="fn2">
      <p>Definitions can appear in any order.<a href="#fnref2" role="doc-backlink">↩</a></p>
    </li>
  </ol>
</section>

Vite Plugin Dogfood

The docs build also imports a .crv file through @markup-carve/vite-plugin-carve and renders the generated HTML during the VitePress build.

Imported Carve

# Plugin Dogfood

This snippet is rendered from a `.crv` import by *vite-plugin-carve*.

Rendered HTML

Plugin Dogfood

This snippet is rendered from a .crv import by vite-plugin-carve.

What this proves

Every construct in the Quick Reference and every pair in the Examples flows through the same parser → AST → renderer pipeline you see here.
Edits round-trip in single-digit milliseconds. Carve's linear-time parsing is the reason.
The current build is vendored from @markup-carve/carve (see docs/.vitepress/carve-lib/ in the repo).

Playground ​

Carve Feature Demo

Headings and attributes

Level 1

Level 2

Level 3

Level 4

Level 5

Level 6

Inline formatting

Links and images

Lists

Blockquotes

Tables

Code and raw blocks

Math

Admonitions and divs

Mentions, tags, and inline extensions

Footnotes

Smart typography

Mermaid (Tier-3 extension)

Vite Plugin Dogfood ​

Imported Carve

Rendered HTML

Plugin Dogfood

What this proves ​

Playground

Vite Plugin Dogfood

What this proves
